What is it?

This is a custom-designed Bluetooth + DAC + Amplifier module made exclusively for the LilyGO T-Display S3 based Internet Radio project (refer to my other listings here for more details about the products it can connect to).

The board integrates:

📡 A Bluetooth audio module for streaming music to:

• Bluetooth speakers

• Bluetooth headphones

• AirPods and similar devices

🔊 A MAX98357A chip functioning as:

• I2S Digital-to-Analog Converter (DAC)

• 3W Class-D audio amplifier

The module is designed with the exact same header layout as the LilyGO T-Display S3, allowing it to connect directly to the board headers without adapter wires.

It is not a standalone product and works only with my official Internet Radio firmware.

Why did you make it?

I designed this module to provide a clean, compact, and fully integrated audio solution tailored specifically for my Internet Radio project.

Instead of combining separate Bluetooth boards, DAC modules, and amplifiers, everything is integrated into one optimized PCB that:

- Matches the LilyGO header layout

• Works directly with my firmware

• Reduces wiring complexity

• Makes the DIY build much cleaner and more reliable

What makes it special?

🎵 Dual audio capability

• Stream audio via Bluetooth to external devices

• Drive a speaker directly using the MAX98357A (3W output)

🔌 Direct header connection – shares the same layout as the LilyGO T-Display S3

🔧 Designed specifically for my Internet Radio firmware

📐 Compact PCB optimized for this exact project

🛠 Ideal for DIY builders

🚫 Not a universal module — works only with this radio design

⚠️ Important Information – Please Read

• Requires LilyGO T-Display S3 (with header pins version)

• The module connects directly to the LilyGO headers

Additional soldering required for:

• Speaker wires

• Battery connection

• On/Off button

Notes:

• Demo youtube videos can be found here: https://studio.youtube.com/channel/UCBU8InaGsqbjO_SgU0FTUOQ

• Requires installation of my custom firmware

• A firmware license key must be purchased separately to activate the radio

• This offer dosnt include the Lilygo T-Display S3 (with header pins) , speaker and on/off switch. They should be purchsed separately.

• If you have any doubts about compatibility or the build process, please contact me before purchasing: themicromaker@outlook.com

• This is a DIY product intended for users comfortable with soldering and electronics assembly.
