Features

• 2 Channel CAN Bus data recorder
• Configurable via JSON file on SD Card
• Records to CSV or raw data file
• Log file analysis available in CSV or graphing via ASAMMDF GUI
• Optional baud rates from 5 Kbit/s to 1 Mbit/s
• Supported rates: 5, 10, 50, 100 125, 250, 500, 800, 1000 Kbit/s
• Future support: CAN-FD Compatibility
• Optional 120 Ohm termination resistors with solder jumper configuration
• RTC (Real-Time Clock) for time-stamped data acquisition.
• Settable via file on SD Card or USB-C connection to a computer
• Wide input voltage range of 6-28v DC
• Reverse polarity protection included

Applications

CAN Bus data transmission is widely used in vehicles, mobile equipment, and industrial communication systems. Modern vehicles often have multiple CAN Bus networks to pass data between ECUs, sensors, and control devices.

Troubleshooting system behavior is essential for ensuring proper operation of CAN Bus systems. Acquiring CAN Bus data is critical for understanding system behavior during testing, design, and reverse-engineering.

Enterprise-grade data acquisition systems are typically expensive, but the BusEye CL2 delivers advanced features at a fraction of the cost of comparable solutions.
