Clock implemented using 74xx series (mostly) TTL integrated circuits and 7-segment LED displays
Designed by Weird Electronics in United States of AmericaThis product is no longer available for sale.
The seller may be offering an improved version or it may be hanging out on the beach, enjoying the retired life.
The PCB, Trimmer Capacitor, and Quartz Crystal only includes just the PCB, a trimmer capacitor and a 32768 Hz quartz crystal required to build TTL Clock Project. All other parts can be purchased from…
Read More…The PCB, Trimmer Capacitor, and Quartz Crystal only includes just the PCB, a trimmer capacitor and a 32768 Hz quartz crystal required to build TTL Clock Project. All other parts can be purchased from most electronic components distributors, or perhaps you already have them in your parts bin! Please refer to the Bill of Materials section of the README file for the parts list.
Looking for the complete kit? Please check TTL Clock
