What is it?

The AgroSense LoRaWAN® GPS Tracker PA1010D is an ideal GPS beacon for geolocation of equipment, same as the AgroSense_NEO-6M ，it reports GPS location every 1 hour( by default, can be set from 5 minute to 24 hours). But the most difference is the PA1010D used on this module. Compares to Neo-6M, the PA1010D module features:

• a. Lower power consumption;
• b. Smaller, with internal antenna;
• c. Quicker positioning;
• d. Higher GPS update frequency

with this GPS module, the AgroSense LoRaWAN® GPS Tracker PA1010D has longer working time (>20 month) with the re-chargeable 18650 battery, it can get GPS data with max 2 seconds.

Also there onboard accelerometer LIS3DHTR to detect vibration and reports via LoRaWAN, suitable for kinds of applications such as asset tracking, farm management.

This product mainly features:

• Compatible with Worldwide LoRaWAN®1.0.3 Networks, Support the universal frequency bands EU868/ US915;
• Long Range: At least 2km in urban scenes and 5 km in line of sight scenes.
• Designed to Use in Harsh Environments: -40℃ ~ 85℃ operating temperature and IP68-rated enclosure, suitable for outdoor use, high UV exposure, heavy rain, dusty conditions, etc.
• Simple to Use: Provides LoRaWAN® DEV EUI/ APP EUI/ APP Key, enable user to finish configuration in few steps.
• Cost-effective: With Makerfabs’ strong ability on production, we make this product cost-effective to users, the cost of our product is approximately half that of similar products currently available on the market, suitable for mass implement in field applications such as farm/greenhouse, etc.
• Support LoRaWAN Downlink, to set Transmit Interval Time (60 minutes by default, Minimum 5 Minutes , 24 hours Max). set/close vibration event reporting threshold;

GNSS

Wireless Parameters

Physical Parameters

AgroSense is a series of Makerfabs wireless LoRaWAN® sensors.

It can cover a transmission range of 2km in urban scenes and 5km in line-of-sight scenes while keeping lower power consumption during the transmission process. Together with a replaceable battery that supports up to 1 years of usage and an industrial IP68 enclosure. It supports at least -40℃ ~ 85℃ operating temperature and can be deployed in harsh environments. AgroSense is compatible with LoRaWAN® V1.0.3 protocol and can work with LoRaWAN® gateway.

With LoRaWAN® gateway, LoRaWAN® sensor report the result to LoRaWAN® networks, such as The Things Network and DataCake, with simply inputting DEV EUI/ APP EUI/ APP Key:

• DEV EUI: Unique identification of device，authorized by IEEE；
• APP EUI: Unique identification of application；
• APP Key: One of the join network parameters on OTAA mode, calculated by DEVEUI；

Part List

• AgroSense_GPS Tracker NEO_6M LoRaWAN® *1;

Usage

• AgroSense Products Datasheet
• Usage Wiki

For country/ area frequency selecting,please check here: regional Parameter
