What is ESP32 Marauder - Double Barrel 5G?

In early 2025, we released the first version of the Double Barrel 5G featuring the BW16 / RTL8720DN chipset. It was the first complete and user-friendly package for Flipper Zero designed to work with 5G Wi-Fi.

In September 2025, we transitioned the Double Barrel 5G to the ESP32-C5 chipset due to its broader compatibility and better support with Marauder firmware. As of December 2025, most Double Barrel 5G units are based on the ESP32-C5 chipset.

The Double Barrel 5G includes two independent Marauder systems. The first is a standalone Marauder kit that can operate without Flipper Zero. The second system, based on the ESP32-C5, is controlled by Flipper Zero and is capable of handling 5G Wi-Fi operations. In addition, the unit also features onboard GPS and Sub-GHz support.

ESP32 Marauder is a linear system/firmware that can perform only one task at a time. This limitation is the core reason behind the Double Barrel design. By running two Marauder systems simultaneously, one can deauth a network with one Marauder while performing a different task with the second Marauder.

For more technical details, please refer to the comparison chart in the listing photos and the individual user manuals.

Specifications of The Double Barrel 5G

The Standalone Marauder comes with

>- ESP32 chipset with an external antenna, - A 2.8-inch touch screen, - An 800mAh embedded battery,
- Onboard GPS access - Micro SD card slot, for updating firmware and data storage (Port C) - USB-C port for charging and alternatively way for firmware update (Top / Position A) - This part of the device can function as a standalone device (i.e., you can use it without Flipper Zero). - The hardware version of this marauder is V6

The ESP32-C5 chipset is controlled by the Flipper Zero, it comes with

>- ESP32-C5 chipset with an external antenna - Dual-Band 5Ghz + 2.4Ghz scanning, de-authentication, on multiple networks simultaneously, recommending on maximum 2 networks at the same time for optimal performance.
- USB-C for firmware update. (Left / Port B) - Micro SD card slot, for data storage (Port D) - This part of the Double Barrel is connected and controlled by Flipper Zero - Marauder firmware version is ESP32-C5

Other:

>- Marauder and second part of the 5G unit (either BW16 or ESP32-C5) can function simultaneously. - CC1101 Chipset(433 MHz), supporting up to 10 dB output per antenna. - GPS Chipset. GPS data is accessible to Marauder and Flipper. - Four Antennas: 2 x 3 dB for Wi-Fi (Dual Marauder), 1 x 1 dB for GPS, and 1 x 3 dB for SubGhz 433 MHz. - Full 3D-Printed Enclosure/Case is also included.

Integration Notes / Update Log

From Batch 3 onward (Nov 2025): >1. The ESP32 refresher included with Batch 1 and Batch 2 packages is no longer required from Batch 3 onward, as the refresher is now embedded directly within the unit. 2. The toggle switch on the left side of the unit (present in Batch 1 and Batch 2) has been removed. Starting from Batch 3, the GPS power supply is now switched automatically.

User Manuals and other resources

>- User Manual for BW16 Version

>- User Manual for ESP32-C5 Version

>- Quick Guide Video: Updating ESP32-C5 Marauder Firmware

>- Quick Guide Video: updating Firmware for the standalone Marauer set

>- Alternative way of updating Firmware for the standalone Marauer set

What is included in the package

>- 1 * ESP32 Marauder - Double Barrel 5G - 3D printed case / enclosure (installed) - 4 * Antenna - 1 * USB-C cable - 1 * Metal stylus - 1 × Quick Note to Get You Started
