48 channel LED strip controller with full MQTT controlDesigned by Futience in Netherlands
What is it? The Jimbi is a multi-function 48-channel LED strip controller. It can be used together with 12V common-anode LED strips. With full color RGBW strips up to 12 channels can be connected to…Read More…
The Jimbi is a multi-function 48-channel LED strip controller. It can be used together with 12V common-anode LED strips. With full color RGBW strips up to 12 channels can be connected to create amazing light experiences for your stairs or other objects. The Jimbi provides 4 hardware inputs to connect switches or sensors which can trigger colors or patterns you can design yourself. Furthermore the Jimbi provides full MQTT control through a wifi connection with your local network or as a standalone network if preferred.
Because it's fun to have something nobody else has! And if you have a great idea, why not bring it to life?
The Jimbi provides an easy to use interface to control multiple channels of LED strips together. You can build your own patterns on an interactive webpage and assign triggers to various trigger inputs. With a wifi connection and a fully-featured MQTT protocol you are in control and can easily implement this device into existing domotica systems like OpenHAB, Domotics or as a standalone application.
The Jimbi is based around the 48-channel PWM controller LT8500 from Analog Devices. Each output can be switched to ground with the onboard FETs, which allows the control of 12V common-anode LED Strips. A total of 4 edge sensitive trigger inputs are provided to trigger patterns or specific colours. The inputs provide a 12V power source to supply power to any sort of external sensor or switch with a digital output.
A Cortex M3 is used to control all the low-level hardware including the LT8500 and provides a gateway to the application layer which is controlled by an ESP8266.
The Jimbi can be connected to a local network or can run standalone. It is powered with a 12Vdc power supply which requires up to 5A of current (internally fused) depending on the amount of LED strips connected.
The ESP8266 takes care of all the configuration and pattern processing while providing an easy to use web interace to configure, backup and restore all your settings. Future updates are possible for both the Cortex M3 and the ESP8266 software by uploading firmware directly from the web interface. The ESP8266 can be connected as a MQTT client to communicate with the outside world. A pattern designer tool is available in the web interace to build your own smart patterns.
The standard product you'll get is without the white housing. I will ship the fully populated and tested PCBs including the ESP-01 module. Both the ESP and the onboard Cortex M3 microcontroller will be pre-programmed with the latest software. Small 10cm cables for all the 48 outputs will be provided free of charge as well as 4 small PCBs with piezzo sensors.
What you'll need to provide yourself:
I've also added an option to purchase the PCB with enclosure and housing (see image). This makes installation much easier and safer but comes with some additional cost.
PLEASE NOTE THE HOUSING IS NOT INCLUDED BY DEFAULT!
