MIDI Serial Interface (with Thru & LED indicators)

Name: MIDI Serial Interface (with Thru & LED indicators)
SKU: 21855
Price: 20.00 USD
Availability: InStock
Rating: 5.00 (2 reviews)

(2 Reviews)

MIDI Serial Interface Breakout Board (with Thru & LED indicators) [5v]

Designed by Data Point Ltd in United Kingdom

MIDI Serial Interface (with Thru & LED indicators) 1

MIDI Serial Interface (with Thru & LED indicators) 2

MIDI Serial Interface (with Thru & LED indicators) 3

MIDI Serial Interface (with Thru & LED indicators) 4

2025-07-11T15:59:31.420Z-s-l1600 (1)..jpeg

2025-07-11T15:59:31.420Z-s-l1600 (3)..jpeg

2025-07-11T15:59:31.420Z-s-l1600 (2)..jpeg

Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

MIDI Serial Interface Breakout Board (with Thru & LED indicators) [5v]

MIDI Serial Interface (5v) Connect your MIDI instruments or create your own Arduino instrument with this MIDI Interface board. Specifications: MIDI In DIN MIDI Out DIN MIDI Thru DIN Serial +5, GND, …

MIDI Serial Interface (5v)

Connect your MIDI instruments or create your own Arduino instrument with this MIDI Interface board.

Specifications:

MIDI In DIN
MIDI Out DIN
MIDI Thru DIN
Serial +5, GND, RX, TX
6N138 Optocoupler
74HC14 Hex Inverter

Measurements:

74mm x 46mm x 23mm
4 x 2mm mount holes

See example Arduino sketches for use with this board on GitHub: github.com/jamesleesaunders/arduino_midi
