A GPS disciplined 10 MHz frequency standard - ±0.1 ppbDesigned by Geppetto Electronics, Ships from United States of America
What is it? This is a GPS disciplined high precision oven controlled crystal oscillator. It has a short-term Allan deviation specification of < 1e-11 @ 𝜏 1s, which means that most of the time the f...Read More…
This is a GPS disciplined high precision oven controlled crystal oscillator. It has a short-term Allan deviation specification of < 1e-11 @ 𝜏 1s, which means that most of the time the frequency will be within 0.1 ppb. GPS is used to continuously discipline the frequency to maintain accuracy.
The unit comes with a 5 VDC power supply (90-240 VAC 50/60 Hz with a North American plug - a passive prong adapter is all that would be required for worldwide use). If you wish to power it yourself, it requires 1A. The output frequency of 10 MHz is provided as either a 5 volt square wave or as a +13 dBm sine wave. The two independent output channels are supplied on BNC jacks. Each channel comes from a separate channel of a fanout buffer, so each should remain independent and stable. The output picture in the gallery shows the TTL waveform delivered through 50Ω coax into a 50Ω load (1.5v P-P, 5 ns rise/fall time to 90%).
The board has three LEDs, labeled FIX, 0 and 1. The FIX LED comes directly from the GPS module and is its indication of a GPS fix. The 0 and 1 LEDs indicate the operating mode of the firmware. If they're blinking back and forth, then there is no GPS fix. If they're not, then they represent a binary value 0-3, which mean coarse (0 - both LEDs out), fine (1 - 0 on, 1 off), finer (2 - 0 off, 1 on) and finest (3 - both on) mode.
The first time it is powered up, it will take several days before the unit will completely stabilize and the phase range will settle, but the frequency will be well disciplined in the meantime. Restarts after that should be able to obtain a lock faster (depending on how long it's been powered off). It is recommended that the unit be (more or less) permanently powered, as the stability of the crystal will improve with age and use.
There is an SMA connector for an external GPS antenna (required and not included). The oscillator will hold-over when GPS is unavailable (however, it will not attempt to "guess" at the aging over time while holding over. Good, constant GPS reception is required for maximal accuracy). There is also a mini-DIN 6 diagnostic connector that supplies a separately buffered PPS output, diagnostic serial output from the controller and serial NMEA I/O from the GPS module.
The board has a 6 pin ISP header for firmware updates. Using it requires an AVR PDI programmer with a 6 pin cable and a pogo pin programming adapter. The firmware requires only standard AVR GCC and AVR libc to build, and is open source and available on GitHub.
The design is intended to produce an Allan variance of 1E-10 or less (assuming good GPS reception and good mechanical and temperature stability). The free-running OH300 oscillator has a short-term spec of no worse than 1E-11 @ 𝜏 10^0, but usually achieves around 8E-12. The pink graphs are comparisons between a unit running against a Thunderbolt after several days of warming up. They are reasonably characteristic.
I had a project where I needed to perform particularly accurate frequency measurements and wanted those measurements traceable to some respected standard. This was the cheapest way I could find to do it. It is not intended to compete with commercial GPSDOs (which are far costlier, but you get what you pay for), but rather offer an entry level frequency standard for a reasonable price.
In terms of accuracy and value, this is the best unit I know how to make. And for most hobbyist and light commercial uses, it should be more than adequate.
