C.Mote BLE5 nRF52840 media remote that can also be used in DIY projectsDesigned by Hobby electronics in Bulgaria
C.Mote is a small and practical remote to control your music if you dont want to deal with your phone or computer everytime you need to skip, control volume or play/pause. So far ive tested it with...Read More…
C.Mote is a small and practical remote to control your music if you dont want to deal with your phone or computer everytime you need to skip, control volume or play/pause. So far ive tested it with iPhone, android, PC, laptop, smart TV and it works without a hitch.
It can ben turned on or off from the side button.
On top it has 5 buttons, top one play/pause, middle left for next song, bottom left for previous song, middle right for volume up, bottom right volume down.
When you first connect it, you need to pair it to your device once and after that whenever you power cycle it connection is almost instantaneous.
On the top right theres a blue led indicating the status of the connection. Solid-connected/blinking-not connected to any device On the top left theres another led which lights up whenever the battery is running low and needs charging. Middle left led lights up during charging and turns off when charging is completed.
When you leave the remote alone it goes to sleep after 8 minutes all lights turn off to save battery juice. Pressing any button wakes up the remote and restores the connection in an instant.
You can charge it simply by connecting any micro usb 5V phone charger or any usb power from pc or laptop.
Pairings are stored in the device and if you need to delete and reset the device you can press and hold the button at the back of the remote for 3 seconds thru the pin hole and when the task is complete upper left led will light up, turning off and on is required after this procedure.
Alternatively if you need to switch devices/connect to another device, simply turn off the bluetooth of your phone or disconnect the remote from your phone. This action will put the remote in discovery mode ready to be paired with another device.
Remote is quite small dimensions are only 6.7 x 4.3 x 1.8 (cm)
For DIY people;
If you simply need nRF52840 with builtin battery and charger circuit, 2 programmable leds, 6 programmable buttons and a nice case this might be the product for you. By removing the back cover you can access the SWDIO, SWCLK, 3.3V, GND pins to install a bootloader. USB is fully functional for arduino usage. You can upload your code using the usb port. Theres also a Qi charger pins for wireless charging but that requires a different back cover.
Nordic Semiconductor nRF52840 SoC
64 MHz Arm® Cortex-M4 with FPU, 1 MB Flash + 256 KB RAM
Bluetooth 5, Bluetooth mesh, Thread, Zigbee, 802.15.4, ANT and 2.4 GHz
2 User programmable leds
6 user programmable tactile switches
Li-Po Battery Charger with Power Path Management
on board voltage divider to measure battery level
battery charging indicator led
3.3V regulator with 600mA rated current output
embedded metal nuts in the 3D printed cover to eliminate wear and tear of the screw grooves
JST 2.0mm battery connector
HUGE NOTE: as you can see from the pictures i designed it to work with 502535 li-ion battery. BATTERY IS NOT INCLUDED IN THIS SALE("tracked postage" option). our national post has strict policy against batteries so its not possible for me to ship it with a battery. Battery connector is JST PH 2.00mm so choose carefully if you source it yourself.
As you can see from the pictures there are quite a bit color combinations for buttons and cases/back covers. Please choose them at the top of the page so i can prepare your order accordingly.
SHIPPING UPDATE:If you are from within EU theres another shipping company which allows me to ship a battery in the package. Rate is abit more expensive for the faster shipping times + battery cost is INCLUDED in the shipping cost. So if you can select the "premium ground rate" option then you will receive the remote with the battery.
Thanks for checking out my listing!
