NESMaker Compatible NES PCB

Name: NESMaker Compatible NES PCB
SKU: 14859
Price: 4.00 USD
Availability: InStock
Rating: 4.81 (4 reviews)

(4 Reviews)

NESMaker Compatible Nes game PCB

Designed by mrTentacle in Sweden



Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

NESMaker Compatible Nes game PCB

What is it? The perfect way of making a physical release of the awesome game you made using NESmaker! Compatible with the programmer that NESmaker shipped with, still available from INFneslives. You …

What is it?

The perfect way of making a physical release of the awesome game you made using NESmaker! Compatible with the programmer that NESmaker shipped with, still available from INFneslives.

You can also program the 39sf040 memory chip using an ordinary chip programmer. Configure according to the picture up top. Pcb color may vary.

Inspired by design from Sealie Computing

Stuff that you need

1x 39sf040 both plcc and dip packages are supported, 29f040 also work future save support is unknown on 29f040.
1x 62256 256k sram
1x attiny13 programmed with AVRCiCzz code found here both smd and dip packages are supported
2x 74ls32
1x 74ls139
1x 74ls377
3x Ceramic capacitors, 100nF / 0.1uF

Why did you make it?

There wasn't a cost efficient option available

No country selected, please select your country to see shipping options.

Change Destination Country:

Quantity	Price
1-9	$4.00
10-24	$3.75
25-49	$3.50
50+	$3.00

Review Breakdown

Average Ratings

Product: (5.00)

Documentation: (4.25)

Shipping: (5.00)

Communication: (5.00)

Christian | Jan. 11, 2023

Great build quality, fast shipping and really helpful seller

I got my order today in amazing quality. Thank you very much for this great boards, your help and nice talk.

Mike | Sept. 16, 2022

Very nice boards and very friendly seller

I have purchased this item multiple times from this seller. He is always very friendly and quick with his replies to messages. The items are always in perfect condition and packaged with care, and the international shipping is very quick. Thank you very much!

Tim | Feb. 2, 2022

NESMaker Compatible NES PCB

I ordered the pre-soldered NESmaker mapper 30 boards. Very good stuff! Also the shipping from Sweeden to the Cleveland area was amazingly fast! Torgot in Sweeden must have some inside postal service connections! Anyways I will order again from Mr. Tentacle most definitely.

David | May 19, 2019

Great board. Having trouble finding schematics

Great PCB. Need to email Mr Tentacle for capacitor values unless i'm missing something... Shipping is amazingly fast considering the distance. Good transaction. Bad documentation?
