ESP-12F AC/DC Power Supply ESP8266 AC90-250V/DC7-12V/USB5V WIFI Single Relay Module Development Board
Sold By MMM999
Buy with confidence.
Our Tindie Guarantee protects your purchase from fraud. Learn More
Thank you for visiting our online store! We've introduced a variety of electronic parts, hope you like it.
Features: On-board mature and stable ESP-12F WIFI module, large capacity 4M Byte Flash The I / O port and UART program download port of the WiFi module are all exported, which is convenient for sec…
Read More…Features:
Function:
ESP-12F AC/DC Power Supply ESP8266 AC90-250V/DC7-12V/USB5V WIFI Single Relay Module Development Board
Introduction to GPIO terminal:
Number | Name | Function | Number | Name | Function |
---|---|---|---|---|---|
1 | GND | Power ground | 13 | IO10 | GPIO10 |
2 | Relay | The relay drive port is driven by IO5 by default. If you want to use other I / O to drive the relay, you can remove R14, and then connect the I / 0 of the drive relay to this Relay pin | 14 | MISO | Slave output master input |
3 | IO2 | GPIO2; UART1_TXD | 15 | IO13 | GPIO13; HSPI_MOSI; UART0_CTS |
4 | IO4 | GPIO4 | 16 | IO14 | GPI014; HSPI_CLK |
5 | RX | UART0_RXD; GPIO3 | 17 | ADC | A / D conversion result. Input voltage range 0 ~ 1V, value range: 0 ~ 1024 |
6 | 3V3 | 3.3V power supply | 18 | 3V3 | 3.3V power supply |
7 | SCLK | clock | 19 | MOSI | Master output Slave input |
8 | IO15 | GPIO15; MTD0; HSPICS; UART0_RTS | 20 | IO9 | GPIO9 |
9 | IO0 | GPIO0 | 21 | CS0 | Chip Select |
10 | IO5 | GPIO5 | 22 | IO12 | GPIO12; HSPI_MIS0 |
11 | TX | UARTO_TXD; GPIO1 | 23 | IO16 | GPIO 16 |
12 | 5V | 5V power supply | 24 | GND | Power ground |
Package includes:
1 x Development Board fully assembled
