VariPower-USB-700 is a USB powered variable power supply(Boost). It is portable and ideal for traveling. Occasionally, we need 7.4, 9 or 12 volts to power a small circuit board while debugging firmware or hardware. Most variable power supplies on the market are large and expensive. They are inconvenient to carry while traveling. So we designed a USB powered variable mini power supply. It can supply several hundred milliamps via a USB cable from your laptop or desktop computer. If the optional USB based AC/DC power adapter is used, the output current can even reach up to 3.0A.

In this version, the load current is not monitored. The power supply is continuously adjustable from around 5V to 32 V using a simple potentiometer. The voltage is shown on the 3-digit segment LED display.

Features:

1. USB powered variable power supply
2. Adjust voltage through Potentiometer
3. A small portable plastic case
4. Input voltage: 5V (Up to 30V if the external USB AC/DC adapter is used.)
5. Output voltage range: 5V to 32V
6. Output current is up to 500mA (Up to 3A if the external USB AC/DC adapter is used)
7. Short circuit protection
